Zhongmuheng GTJZ series self-propelled scissor lifts, working height from 3m to 14m. Electric hydraulic drive, long battery life, for factory, warehouse and airport high-altitude work.
PRODUCT DESCRIPTION
Self-propelled scissor lift can move by itself without external force and external power source. It can work only with one person and it is very convenient and efficient. It is widely used for repairing, cleaning, maintaining, and more high altitude operations.Its platform height is from 3m to 14m. Load capacity is from 230 to 550 kilogram.
PRODUCT CUSTOMIZATION
We can customize products according to your requirements to make products more in line with your needs. Like color, brand, logo, nameplate and so on.
PRODUCT DETAILS
Self propelled scissor lift uses whole electrophoresis. The shaft pin is maintenance-free salt bath nitriding treatment. The scissor lift equips with protective system, includes overload protection, pit protection,
inclined protection, emergency descent system,emergency stop button and secondary descent system.
The pedal extension platform can be quickly rolled out to the operating point.
The foldable guardrail reduces the volume of the whole machine.
25% climbing ability, able to smoothly climb up the slope.
Swivel chassis for easy maintenance.
Fault codes are automatically displayed for easy maintenance.
| Parameters | GTJZD03 | GTJZD04 | GTJZ06 | GTJZ06A | GTJZ08 | GTJZ08A | GTJZ10 | GTJZ12 | GTJZ14 |
| Max. lifting height | 3m | 4m | 6m | 6m | 8m | 8m | 10m | 11.8m | 13.8m |
| Max. working height | 5m | 6m | 8m | 8m | 10m | 10m | 12m | 13.8m | 15.8m |
| Max. loading capacity | 230kg | 230kg | 550kg | 380kg | 450kg | 230kg | 320kg | 320kg | 227kg |
| Loading capacity of extension platform | 113kg | 113kg | 113kg | 113kg | 113kg | 113kg | 113kg | 113kg | 113kg |
| Platform size | 1.29X0.7m | 1.29X0.7m | 2.29X1.13X1.1m | 2.29X0.81X1.1m | 2.29X1.13X1.1m | 2.29X0.81X1.1m | 2.29x1.13x1.1m | 2.29x1.13x1.1m | 2.67x1.13x1.1m |
| Platform extension size | 0.6m | 0.6m | 0.9m | 0.9m | 0.9m | 0.9m | 0.9m | 0.9m | 0.9m |
| Min. ground clearance(Close/Open) | 0.06/0.015m | 0.06/0.015m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m |
| Wheelbase | 1.05m | 1.05m | 1.89m | 1.89m | 1.89m | 1.89m | 1.89m | 1.89m | 2.26m |
| Min. turning radius（Outer wheel / Inner wheel） | 1.35m/0.3m | 1.35m/0.3m | 0/2.2m | 3.1m/0m | 0/2.2m | 0/3.1m | 2.2/0m | 2.2/0m | 2.7/0m |
| Drive motor | 2X24V DC/0.4kw | 2X24V DC/0.4kw | 24V DCX3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/4.5kw | 24V/4.5kw |
| Lifting motor | 24V DC/0.8kw | 24V DC/0.8kw | 24V DCX3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/3.3kw | 24V/4.5kw | 24V/4.5kw |
| Ground speed(Close) | 4.0km/h | 4.0km/h | 3.5km/h | 3.5km/h | 3.5km/h | 3.5km/h/0.8km/h | 3.5km/h | 3.5km/h | 3.5km/h |
| Ground speed(Open) | 0.5km/h | 0.5km/h | 0.8km/h | 0.8km/h | 0.8km/h | 3-5m/min | 0.8km/h | 0.8km/h | 0.8km/h |
| Lifting speed | 4-6m/min | 4-6m/min | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min |
| Battery | 2X12V/80Ah | 2X12V/80Ah | 4X24V/200Ah | 4X12V/200Ah | 4X12V/200Ah | 4X12V/200Ah | 4x12V/200Ah | 4x12V/200Ah | 4x12V/200Ah |
| Max. gradeability | 25% | 25% | 25% | 25% | 25% | 25% | 25% | 25% | 25% |
| Max. allowable working angle | 2°/3° | 2°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° |
| Tyre | φ230X80mm | φ230X80mm | φ381X127mm | φ381X127mm | φ381X127mm | φ381X127mm | φ381X127mm | φ381X127mm | φ381X127mm |
| Overall size(Folding guardrail) | 1.46X0.76X1.59m | 1.46X0.76X1.67m | 2.48X1.19X1.68m | 2.48X0.81X1.73m | 2.48X1.19X1.82m | 2.48X0.85X1.85m | 2.495X1.19X1.92m | 2.495X1.19X2.05m | 2.495X1.19X2.06m |
| Overall size(Unfolded guardrail) | 1.46X0.76X2.01m | 1.46X0.76X2.03m | 2.48X1.19X2.19m | 2.48X0.81X2.18m | 2.48X1.19X2.32m | 2.48X0.85X2.3m | 2.495X1.19X2.45m | 2.495X1.19X2.585m | 2.495X1.19X2.595m |
| Overall weight | 815kg | 890kg | 2050kg | 1880kg | 2190kg | 2030kg | 2500kg | 2950kg | 3390kg |
